Spearhead Multi-Cut 420
11
Options
 An extra two wheels are available for the wings to improve contour following
on uneven ground and reduce wear on the skids.
 Three blades per rotor (standard 2) to improve cutting and mulching.
 Lighting kit.
Transportation
First disengage the PTO drive and half raise the machine, fold the wings fully upright
and secure rams with locking bar (Fig. 6). Never transport along public highways with
the wings only supported by the hydraulics.
Please observe Public Highway Regulations, concerning the towing of implements,
and securely attach a registration and lighting board.
Warning
Do not run the machine with the wings raised, serious
damage will result to the drive line.
Warning
Avoid transporting machine at high speed over rough ground
Maximum speed on highway – 20mph (30kph).
Fig. 6
Transportation position
Secure wings
with transport
locking bar
