SPEC-D Tuning 2LHP-DEN07-TM - Headlight Removal and Disconnection; Step 1: Open Hood and Remove Top Bolts; Step 2: Remove Wheel Well Bolts; Step 3: Remove Hidden Bumper Bolt

1. Open the hood, there are six bolts that needs to be
removed
3. Remove one hidden bolt between the bumper and fender
2. Remove two bolts under wheel well
4. Remove two headlight bolts
W W W . S P E C D T U N I N G . C O M
p1
If you experience any difficulties t hat the instruction did not cover, Please seek local auto shop for advise.
Please wear protection b efo re you wo rk on you r vehicle.
An assistant is helpful when r emoving the front bumper.
Please be careful while working w ith the bumper or body part to avoid scratching.
Do not make direct contact with the halo gen bulb or the wire assembl y un til the u nit has cooled down after use
.
2007-2010
GMC YUKON DENALI PROJECTOR HEAD LIGHTS
INSTALLATI ON INSTRUCTIO NS
