Users manuel Caddy e-Move Version 01.05
3.8 Noise emission
The Caddy e-Move is fitted with electric motors that have a sound emission
of <63 dB at 50 cm distance
3.9 Freewheel
If failure occurres, or the batteries are discharged. It may be necessary
that the Caddy e-Move must be moved manually. For this purpose the
motors need to be unlocked.
To unlock the left motor, the left handle (Figure 7 F) must be turned a quarter of
a turn clockwise.
To unlock the right engine, the right handle (Figure 7 G) must be turned a quarter
of a turn anti-clockwise.
(Figure 7 F) at the hands of the clock in a quarter of a turn to be rotated.
Locking is done in reverse order.
Warning: When the motors are unlocked, the Caddy e-Move has no
brakes
