18
WARNING! The bicycle comes with one 5 mm solid spacer and 35
mm of scalloped spacers. Only the solid spacer should be used
above the stem. The scalloped spacers should only be used below
the stem, i.e., between the stem and the headset cover.
WARNING! Do not apply grease or carbon assembly compound
(carbon paste) between the stem and the steerer tube, and do not
twist the stem onto the steerer tube. This can result in damage to
the composite surface, which may result in a catastrophic failure
of the fork, resulting in serious personal injury or death.
HEADSET COVER: 8.5 mm
SOLID SPACER ONLY
OVER STEM: 5mm
SCALLOPED
SPACERS ONLY BELOW
STEM: MAX 35 mm
