Specialized Speedzone Comp - Installing Speed and Cadence Transmitter

5
• Adjust spoke magnet so path of rotation passes along the
groove area inside the sensor. IMPORTANT: Placing magnet
outside the groove path may cause improper reading.
• Attach the cadence magnet with self adhesive pad to the
crank arm, and position the sensor’s raised line within the
magnet’s rotation path.
Installing speed & cadence transmitter
!
1-5mm
1/16 - 1/4 in.
!
