CONNECT POWER CABLE
1. WHEN USING 12 VOLTS DC (constant voltage 500mA)
2. WHEN USING 24 VOLTS AC (40 Volt Amps)
3. CONNECT VIDEO CABLE
1) WHEN USING IT AS ANALOG OUTPUT,
CONNECT YELLOW COLOR BNC CABLE TO THE BNC JACK.
2) WHEN USING IT AS TVI OUTPUT,
CONNECT BLACK COLOR BNC CABLE TO THE BNC JACK.
DC 12V Power Supply
Power Input :R ED
Center : (+)
C V B S
T V I
LBACK:(-)
RED(+)
Power Supply
AC 24V
