SPECIFICATIONS
Type Public Address Mixer Power Amplifier
Model No. PBM-15 PBM-30
Power supply AC 120V, 50/60Hz AC 120V, 50/60Hz
Rated output
power
15W RMS 30W RMS
Frequency
response
50~15 KHz ±3dB 50~15 KHz ±3dB
Total harmonic
distortion
1% or less at 1 KHz at rated output 1% or less at 1KHz at rated output
Input
sensitivity and
impedance
TEL :100mV/600 Ohm, Balanced
MIC-1:1.0mV/600 Ohm, Balanced
MIC-2:1.0mV/600 Ohm, Balanced
AUX:200mV/50K Ohm, Unbalanced
TEL :100mV/600 Ohm, Balanced
MIC-1:1.0mV/600 Ohm, Balanced
MIC-2:1.0mV/600 Ohm, Balanced
AUX:200mV/50K Ohm, Unbalanced
S/N Ratio
MIC-1 Better than 55 dB
MIC-2 Better than 55 dB
TEL Better than 60 dB
AUX Better than 70 dB
MIC-1 Better than 55 dB
MIC-2 Better than 55 dB
TEL Better than 60 dB
AUX Better than 70 dB
Speaker outputs
4 Ohm, 8 Ohm, 16 Ohm
25V, 70V line outputs
4 Ohm, 8 Ohm, 16 Ohm
25V, 70V line outputs
*MOH output
600 Ohm @ 1V and
8 Ohm - 1Watt
600 Ohm @ 1V and
8 Ohm - 1Watt
Mute level
MIC-2/ AUX≧ 40 dB MIC-2/ AUX≧ 40 dB
**VOX level
MIC-1/TEL 0~40 dB Adjustable** MIC-1/TEL 0~40 dB Adjustable**
Tone control
Bass: ±10 dB at 100Hz
Treble: ±10 dB at 10KHz
Bass: ±10 dB at 100Hz
Treble: ±10 dB at 10KHz
Dimensions
272mm(W)x88mm(H)x240mm(D)
10.7”(W)x3.5”(H)x9.4”(D)
272mm(W)x88mm(H)x240mm(D)
10.7”(W)x3.5”(H)x9.4”(D)
Weight Approx 8 lbs(3.7 kgs) Approx 22 lbs (10.0 kgs)
Finish Black Black
Mounting
options
Table top or 19” rack or wall
mountable (Use # PBM-RK1 rack
mount bracket)
Table top or 19” rack or wall
mountable (Use # PBM-RK1 rack
mount bracket)
*MOH = Music on hold **Factory set : - 40 dB
