Chapter
7 Drawings
EBE-1 23
Figure 3: Evaporator overview and dimensions
50mm thimble
HV connector
Water in/out
Rotary drive
2.75" (NW35CF)
Mounting flange
Flux monitor
Shutter
200
203
e- e-
e- e-
Filament
Evaporated material
Electrons
Rod
