Pairing the remote control with the transmitter
First, make sure the transmitter and the remote control are turned off. Then press and hold the Manual
button and turn on the transmitter. During the next 6 seconds repeat the same steps on the remote control.
The transmitter’s displays show the following information:
The transmitter and remote’s display show Pairing OK for one second and then the
same information as shown at the laser’s LCD to indicate the transmitter has been
matched with the remote control.
To pair the HL760 receiver with the transmitter
Make sure the transmitter is turned off.
First, turn on the receiver, then press and hold the Deadband (A) and Audio (B) buttons for two seconds.
After two seconds, the display shows MENU first, then RDIO
Press and release the Enter button – display shows the current radio mode.
If not already set to LS, press Units (C) button (current mode flashes)
and then press Deadband (A) or Audio button (B) until LS is displayed.
Press Units (C) button again to enter selection.
Press and release the Audio (B) button – display shows PAIR.
Press the Units (C) button again – the display shows PAIR and a rotating bar.
Then press and hold the Manual button and turn on the transmitter
(Battery LED flashes fast). After completing PAIR, OK will be displayed.
The laser pairs now automatically with the new receiver and turns back to the standard function.
Press and release the HL760 Power button two times to exit the menu at the receiver.
A laser symbol and an antenna is lit to confirm the receiver is ready for communication
with the laser.
10
or
or
A
B
C
