36
TECHNICAL SPECIFICATIONS
MODEL SP-A1500D SP-A2100
4 OHMS / 14.4V (THD<=1.0%)
All channels driven simultaneously 450W x 1 100W x 2
4 OHMS / 14.4V (THD<=0.3%)
All channels driven simultaneously 350W x 1 60W x 2
2 OHMS / 14.4V (THD<=0.3%)
All channels driven simultaneously 400W x 1 98W x 2
1 OHMS / 14.4V (THD<=1.0%)
All channels driven simultaneously 1000W x 1 n.a.
4 OHMS BRIDGED / 14.4V (THD<=0.3%)
All channels driven simultaneously n.a. 180Wx1
DAMPING FACTOR
All channels @ 4ohms/100Hz >100 >100
SIGNAL-TO-NOISE RATIO
(A-weighted - all channels) >85dB >90 dB
FREQUENCY RESPONSE
(all channels, x-over set to full
range op-mode, -3dB) 15Hz-150Hz 20Hz–30kHz
CHANNEL SEPARATION
(all channels) n.a. >50dB
INPUT SENSITIVITY
(all channels) 200mV–5V 200mV–5V
INPUT IMPEDANCE 47Kohms 47Kohms
INTEGRATED ELECTRONIC X-OVER
X-over slope rates 12dB/oct. 12dB/oct.
Variable highpass x-over freq 15–55Hz 40–300Hz
Variable lowpass x-over freq 40–150Hz 40–300Hz
DIMENSIONS (WXDXH MM) 292X254X47 334X254X62
