4-4 Chapter 4: Programming Your Module
Owner’s Guide 0300199-01 Rev. D
NOTE
CTR8_Config and CTR8_Input contain the configuration, data, and status
tags for the CTR8 module. The other tags are used for performing various
functions with your module via ladder logic.
NOTE
Be sure all tags are displayed before moving them. Select Display All from
the Edit drop down window.
NOTE
The “Local:3:I” and “Local:3:C” tags are not copied.
