Spectrum E31U2V1 User Manual

!
To mount the device on a wall:
1. Install the 2 screws horizontally on the wall 140 mm (5.51
inches) apart.
You can mount the E31U2V1 on a wall using the 2 mounting
brackets on the side of the device. Two round or pan head screws
are recommended. See the figure below for measurements.
3
Note: The screws should protrude from the wall so you can fit
the device between the head of the screws and the wall. If you
install the screws in drywall, use hollow wall anchors to ensure
the unit does not pull away from the wall due to prolonged
strain from the cable and power connectors.
2. Mount the device on the wall
•
DEVICE WALL MOUNT INSTRUCTIONS
E31U2V1 Quick Installation Guide
NOTE to CATV SYSTEM INSTALLER:
This reminder is provided to call the CATV systems installer's attention
to section 820-93 of the National Electric Code, which provides
guidelines for proper grounding and in particular, specify that the
Coaxial cable shield shall be connected to grounding system of the
building, as close to the point of cable entry as practical.
Label
Size in Millimeters (mm)
A
9.5 +/- 0.2
B
3.7 +/- 0.1
C
34.5 +/- 0.2

Spectrum E31U2V1 Specifications

General

Brand	Spectrum
Model	E31U2V1
Category	Modem
Language	English
