Speechi SPE-VA460 - Quick Start; Interfaces and Device Startup; Audio and Video Output

Quick Start
© Speechi
User Manual l SPE-VA460
5
1. Quick Start
1.1. Interfaces
INTERFACES
USB
USB audio video in out, type C
HDMI
HDMI video output
LINE IN
Audio linear input
LINE OUT
3.5mm linear output
Extension Mic
RJ45 extension mic
Power Jacket
HEC3800 power socket(DC12V), input AC110V-AC220V, output DC12V/2A
1.2. Device Startup
1.2.1. Power On
Connect device to power socket with DC12V power adapter.
1.2.2. Statue Indicator Light
INDICATOR LIGHTS
Green lights
Boot initialization in progress
continuously run left to right
In Bluetooth pairing mode
Blinking Blue Lights
Bluetooth pairing finished
Lights Turn Blue and Stay 3S
Working statue：
- When turn off Auto-framing & Voice tracking, all light
turn green
- When turn on Auto-framing & Voice tracking, partial
light turn green
Solid Green Light
Standby statue(Device on without video)
Blinking Green
Microphone Muted
Light
Volume up/down
Solid Red Light
Partial light turns green according to the voice source
1.3. Video Output
 USB：Connect device to Pcs through USB cable, and open the video software to select device to
output.
 HDMI：Connect device to monitor through HDMI cable, and then select the correct input source on
the monitor to output.
1.4. Audio Input
 Built-in audio：It is default that the device pick up voice through built-in mics
