Page 10
ITEM NO. PART NO. DESCRIPTION QTY.
1 O/L 5/16” Flat Washer 8
2 O/L 5/16”-18UNC Nylock Nut 4
3 O/L 5/16” x 1-1/2” GR 5 Bolt 4
4 40118800 Tank 1
5 39060400 Filter Assembly 25 PSI 1
390604B0 Filter Base 1
5A 390601A0 Filter Element 1
6 39034900 3/4” Hex Nipple 1
7 39038300 Straight Fitting, 3/4” NPT to 1
3/4” ID Tube
8 39032000 3/4” NPT x 3/4” Tube 1
9 39073600 Pump/Engine Assy. 1
10 071022WC Pivot Pin 1
11 O/L 1/2”-3/4” Hairpin Cotter 1
12 39027500 1/2” x 38” Pressure Hose 1
13 39027400 3/4” x 56” Return Hose 1
14 39027300 3/4” Suction Hose 1
15 39031600 Worm Gear Clamp 3
16 39037600 Breather Cap/Dip Stick 1
O/L- Obtain locally. Common fasteners available through
hardware and farm stores.
TANK/ENGINE ASSEMBLY BREAKDOWN
PUMP/ENGINE ASSEMBLY BREAKDOWN
5A
ITEM NO. PART NO.. DECSRIPTION QTY.
1 O/L M8 x 1.25 x 20mm Bolt 4
2 O/L 5/16” Regular Lock Washer 4
3 39053900 196CC SpeeCo Engine 1
4 390705B0 11 GPM Pump 1
5 400835L0 Jaw Coupler, 3/4” Bore 1
6 400833L0 Law Coupler, 1/2” Bore 1
7 400834L0 Rubber Spider for Coupler 1
8 40034800 3/8” x 1” Square Key 1
9 O/L 5/16”-18 UNC Nylock Nut 4
10 O/L 5/16” x 1-1/4: GR5 Bolt 4
11 40081200 Pump Mount 1
O/L- Obtain locally. Common fasteners available through
hardware and farm stores.
