VAJRA80 Rotorcraft User's manual
17 / 36
XIII. LED status Light
Instruction light :There are two mold light flash:. No-GPS and GPS Mold
1.Initialization:the tail of red light start flashing after connecting battery about 5s. then red flashing about 3s
2. After Initialization
(1)No-GPS signal:
Disarmed: Green, Yellow and Red light changing flash.
Arming: Lights out or One of three lights holds on for 3 second.
Armed: Yellow and red light changing flash
(2)GPS signal
Disarmed:Green and Yellow changing flash.
Arming: Lights out or One of two lights holds on for 3 second.
Armed: Yellow flash
