SpeedyBee F7 V3 BL32 50A 30x30 Stack - Part 3 - SpeedyBee BL32 50 A 4-in-1 ESC; Layout

Layout
Pa 3 - SpeedyBee BL32 50A 4-in-1 ESC
10/13
MOTOR 2
MOTOR 1MOTOR 3
MOTOR 4
CNC Heat Sink
Capacitor pin
hole(GND)
Capacitor pin
hole(BAT+)
8pin connector(to FC)
Power Inductor
Driver chips
Driver chips
F4 MCUs
TVS Diode
BAT+BAT-
