Specications
13/13
Product Name SpeedyBee BL32 50A 4-in-1 ESC
Firmware J-H-50
Configurator Download Link
http://github.com/bitdump/BLHeli/releases
Continuous Current 50A * 4
Burst Current 55A(5seconds)
TVS Protective diode Yes
Heat Sink Yes
External Capacitor 1000uF Low ESR Capacitor(In the package)
ESC Protocol DSHOT300/600
PWM Frequency Range 16KHz-128KHz
Power Input 3-6S LiPo
Power Output VBAT
Current Sensor Support (Scale=490 Offset=0)
ESC Telemetry supported
Mounting 30.5 x 30.5mm( 4mm hole diameter)
Dimension 45.6(L) * 40(W) * 8.8mm(H)
Weight 19.2g with heat sink
