EN
6
Bind/Prog port
Bind/Prog/SRXL2 port
Bind/Prog/SRXL2 port is shared with the
SRXL2 port on the side of the case.
If a remote receiver is connected to one
SRXL2 port and the SkyID module is
connecrted to the other SRXL2 port, there
won’t be telemetry from the SkyID module.
Bind/Prog/SRXL2 port
XBUS port
XBUS port
Connect with your Receiver
4-Pin ZH port for power and
status updates over telemetry.
A9500 Remote ID Module Connection
AR6250MHX Helicopter Receiver
AR630 Receiver
AR637T Receiver
AR10100T Receiver
