Spektrum AR410 - Transmitter and Receiver Diagrams

EN
5
Antenna
B Switch (Ch 5 Default)
D Switch (Ch 7 Default)
RGB LED
H Switch
(Throttle Cut Default)
F Switch
(Dual Rate Default)
4 Green LEDs
Throttle/Rudder Gimbal
(Mode 2)
Aileron Trim (Mode 2)
Elevator Trim (Mode 2)
Power Button
Neck Strap Hook
Throttle Trim (Mode 2)
Elevator/Aileron Gimbal
(Mode 2)
Transmitter Diagram
A Button
(Channel 6 Default)
Rudder Trim (Mode 2)
Integrated Handle
Wireless Trainer Port
Programming Port
Battery Holder
