EN
Binding Receiver to Transmitter
In order to operate, the receiver must be bound to the transmitter. Binding
is the process of programming the receiver to recognize the GUID (Globally
Unique Identifier) code of a single specific transmitter. When areceiver is
bound to atransmitter/model memory, the receiver will only respond to that
specific transmitter/model memory.
Binding
1. With the receiver off, insert the bind plug into the BIND port in the receiver.
2. Power the receiver through any port. If an ESC is being used, power on the
ESC with the ESC lead plugged in the throttle channel port. The orange LED
will flash continuously, indicating that the receiver is in bind mode.
3. With the throttle channel in the desired preset failsafe position (generally
full brake and neutral steering), initiate the bind process with your Spektrum
transmitter. This stores the failsafe position. Continue to hold the failsafe
position until the binding process is complete.
4. The LED on the receiver should now be solid, indicating asuccessful bind
has taken place.
5. When the bind process is complete, remove the bind plug from the receiver
and store it in a convenient place. Failure to remove the bind plug will result in
the receiver going back into bind mode.
The only time it is necessary to rebind is if different failsafe positions are
desired e.g., servo travel has been reversed after the initial bind, or if you want
to use the receiver with a different model memory.
Powering the receiver with an ESC
Battery To Motor
Electronic
Speed Control
Steering Servo
Receiver
Receiver
Steering Servo
Throttle Servo
Battery
Powering the receiver with a separate receiver pack
