Sphere MPPT Series - Page 21

 BAT indicator:
Indicator state
Battery state
Steady on
Normal battery voltage
Slow flashing
(a cycle of 2s with on and off
each lasting for 1s)
Battery over-
discharged
Quick flashing
(a cycle of 0.2s with on and off
each lasting for 0.1s)
Battery over-voltage
 LOAD indicator:
Indicator state
Load state
Off
Load turned off
Quick flashing
(a cycle of 0.2s with on and off
each lasting for 0.1s)
Load overloaded/
short-circuited
Steady on
Load functioning
normally
 ERROR indicator:
Indicator state
Abnormality
indication
Off
System operating
normally
