Peel the protective film
All of the acrylic parts have a cling film that protects the pieces during manufacturing
and transport. The film or tape may be blue, brown or white. Start at a corner, and
remove the film from both sides of each piece.
Ready the motor, motor mount, and fasteners
Line up the 2 long screws, 2 small washers, 2 motor mount acrylic pieces, and weld
nuts as you see below.
Motor mount arm side
2x 1” 4-40 screws
2x #4 weld nuts
2x #4 washers
Motor mount wire side
Motor
Wire
Side
Nub
