Spimbey 2001 - Swing Hangers (Step 8)

Parts Required:
220 X 1
221 X 1
Swing
Hangers X 6
SWING HANGERS
8
Orient swing hangers
to swing as shown
Note the hole location in both
beams for correct orientation
Install swing hangers into (6) holes as shown
5/16 Flat Washer X25/16 Lock Nut
14.00” [35.6]
40.19”
[102.1]
220
221
1. Locate and install parts as shown.
2. Make sure to orient hangers as shown.
