Spin ATF 2 BASIC - Page 17

19/11/2013 Vers. 1.1 17
Check whether the connection has been made correctly, by turning on the car and holding the machine in standby.
Check that the 'Pressure' gauge raises properly, showing the oil pressure from the gearbox of the car.
These are the possible connection modes:
Diagram 1
Figure 21 – Connecting the station to the car (2) (3)
