ZS Alloy, ZS Carbon and ZS OPEN Jammers
Maintenance
Maintenance
ZS Alloy / Carbon
how to use
pages 8-11
installation
pages 16-17
spares
pages 34-35
Spinlock ZS Jammers are made from the highest quality materials for
durability and low maintenance in a harsh marine environment.
ZS Jammers are carefully designed for easy and regular servicing at sea. Their
life and performance will be improved if regularly flushed with fresh water.
The jaws can be easily removed for inspection and replacement:
For ZS Alloy and ZS Carbon
• Remove the screw securing the rear block.
• Remove rear block.
• Pull out the handle and jaw assembly.
For ZS OPEN
• Open the sideplate to allow removal of the jaw assembly -
compress jaws together to extract sideways.
ZS Alloy, ZS Carbon and ZS Bonded
All
• Check for excessive wear on the grip surface - the black anodised
surface, if worn, will have silver aluminium showing through.
• Check condition of the white bearings surfaces are clean and smooth.
Replace if necessary.
• Ensure all internal faces are clean and smooth.
The white jaw bearings should be lubricated only with silicone grease.
Do not use mineral oil or solvent based lubricants like WD40.
Replacement jaw sets must be installed with grease provided.
For further information and instructions on maintenance of ZS jammers,
please refer to the Spinlock website or contact Pro Support.
ZS OPEN
