setting is only effective when the machine is set on the vertical
oscillation mode (horizontal vertical oscillation mode, 2-line vertical
oscillation mode or vertical oscillation mode).
w1-w2: The button is used for horizontal 2-line oscillation modes,
which includes horizontal 2-line oscillation and vertical horizontal 2-line
oscillation. In such modes, the machine is shooting balls to a defined
width. W1 stands for the 2-line width range on the backhand side and
W2 stands for the 2-line width range on the forehand side. Pressing
once on the w1-w2 button will have the user set the W1 level with a
minimum level of 1 and a maxim level of 9. Pressing again on the
w1-w2 button will have the user set the W2 level with a minimum level
of 1 and a maxim level of 9. This setting is only effective when the
machine is set on the 2-Line oscillation mode (2-line oscillation or 2-line
vertical oscillation).
Oscillation Mode Setting and Buttons
SPINSHOT-Plus model can support different oscillation modes, or a
combination of oscillation modes. Overall it can support 5 types of oscillation:
Type-1: RANDOM HORIZONTAL OSCILLATION;
Type-2: 2-LINE HORIZONTAL OSCILLATION;
Type-3: VERTICAL OSCILLATION;
Type-4: RANDOM HORIZONTAL AND VERTICAL OSCILLATION;
Type-5: 2-LINE HORIZONTAL AND VERTICAL OSCILLATION;
RANDOM: Pressing this button will set machine to horizontal
oscillation mode. In this mode, the machine will randomly shoot balls
horizontally. Ball speed, height, spin and feed rate can be adjusted for
the random oscillation mode.
When the machine is set to the horizontal oscillation mode, the user
can still press the vertical oscillation to switch the machine to RANDOM
HORIZONTAL AND VERTICAL OSCILLATION mode. This is an
oscillation mode combining both horizontal and vertical oscillations.
For this oscillation mode, the h1-h2 setting needs to be applied to
define the 2 height levels of vertical oscillation.
2-LINE: Pressing this button will set the machine to the 2-line
