IM-S21-01 CH Issue 7
7
SA control
system actuator
When medium is steam fit
a trap set to the drain line.
SA
control
valve
Pipeline
strainer
Fig. 1 Typical installation showing recommended bypass
Steam
Condensate
Isolating
valve
Isolating
valve
Eccentric reducers
Bypass
Manual
regulating
valve
