IM-P122-02 CMGT Issue 11
14
BPT13 Balanced Pressure Thermostatic Steam Traps
The spare parts available are shown in solid outline. Parts drawn in a grey line are not supplied as spares.
Available spares
Maintenance kit 3, 4, 5, 6, 7, 8, 9
Cap gasket Earlier models (packet of 3) 3
'O' ring Current models (2 x packet of 3) 3
Screen (packet of 3) 3, 9
Note: Earlier models were fitted with conventional gaskets. Current models are fitted with an 'O' ring to seal
the cap. There are two types of 'O' ring. The 'O' ring used is dependant on the body type.
How to order spares
Always order spares by using the description given in the column headed 'Available spares' and state the
size, model number and capsule reference.
Example: 1 - Capsule and seat assembly for a Spirax Sarco ½" BPT13S balanced pressure thermostatic
steam trap.
Note: If a non-standard fill capsule has been fitted then the name-plate on the cap is marked with the letters
'NTS' or 'SUB'. The near-to-steam (NTS) capsule can be used, for example, on hospital sterilisers and wet
steaming ovens. Sub-cooled-capsules (SUB) can be used, for example, on vacuum return systems. For
further details on capsule fill and operation see Section 2.1. Capsule type should be specified on the order
otherwise a standard version will be supplied. Older models may be marked slightly differently. Possible
markings are 'G', or 'F'. 'G' is equivalient to 'NTS' and 'F' is equivalent to 'SUB'.
7. Spare parts
