BPT13 Balanced Pressure Thermostatic Steam Traps
2.1 Description
The BPT13 is a readily maintainable brass bodied, balanced pressure thermostatic steam trap.
Available types
BPT13A Angled connections
BPT13AX Angled connections with strainer screen
BPT13S Straight connections
BPT13SX Straight connections with strainer screen
BPT13UA Angled connections, union inlet
BPT13UAX Angled connections, union inlet with strainer screen
BPT13US Straight connections, union inlet
BPT13USX Straight connections, union inlet with strainer screen
Capsule fill and operation
When placing an order always state the capsule fill:
Standard capsule Is marked with 'STD' for operation at approximately 12 °C (53 °F) below steam saturation
temperature.
Optionally The capsule can be supplied for sub-cooled 'SUB' operation at approximately 24 °C
(75 °F) below steam saturation temperature.
For critical applications the 'NTS' fill capsule should be selected which operates at
approximately 4 °C (7 °F) below steam saturation temperature.
Standards
This product fully complies with the requirements of the European Pressure Equipment Directive
2014/68/EU.
Certification
This product is available with a manufacturers' Typical Test Report.
Note: All certification /inspection requirements must be stated at the time of order placement.
Note: For further product data see the Technical Information Sheet TI-P122-01.
