MINIMUM INSTALLATION SPACING
INSTALLATION INSTRUCTIONS
This machine may be installed free standing as well as in a recessed area, closet,
or alcove. The installation spacing is in inches and is the minimum acceptable.
*Additional spacing should be considered for easy installation, servicing
and compliance with local codes and ordinances. Installations must
conform with the minimum dimensions indicated.
Floor must support 280 lbs. and be a solid level surface. To avoid damage
to the ooring, do not install on carpet.
RV/Marine lnstallations - When locating the appliance in a towable trailer
or watercraft, position the machine over the axles or mid-ship where
movement is at a minimum. For RV or marine applications, please visit the
Splendide website or call 1-800-356-0766 for the available installation kits.
Unpacking
1. Remove the washer from its packaging.
2. Make sure that the washer has not been damaged during the
transportation process. If it has been damaged, contact the retailer and do
not proceed any further with the installation process.
Dispose of/recycle all packaging materials.
UNPACKING AND LEVELING
Leveling
1. Install the washer on a at sturdy oor, without resting it up against
walls, furniture cabinets or anything else.
2. If the oor is not perfectly level,
compensate for any unevenness by
tightening or loosening the adjustable
front feet (see gure); the angle of
inclination, measured in relation to the
worktop, must not exceed 2°.
Leveling the machine correctly will provide it with stability, help to avoid
vibrations and excessive noise and prevent it from shifting while it is operating.
REMOVING THE TRANSIT SCREWS
For transportation, the inside of the machine is supported by screws, rubber
grommets and spacers on the back panel. Before using the washer, these
items MUST be removed.
Important: Transit screws and spacers must be removed before operating
the machine to allow proper operation of the machine and to prevent
damage to the appliance.
After positioning the washer near the installation location, remove the four
screws (see gure), with the rubber grommets and plastic spacers that are
attached to them.
Important: Retain the transit screws, spacers and rubber tubes. These items
should be reinstalled to prevent damage if or when you transport the
machine in the future.
NOTE: If the washer will be installed with a stacked dryer, refer to your dryer’s User Manual for ventilation requirements.
For closet installations, door ventilation is not required.
