Data di emissione: Maggio, 2016 Revisione: 6 Pag. : 52/64
Caution
To avoid electrical shock or contact with
moving parts, before proceeding with the
disassembling operations, make sure all
switches are in “OFF” position and that the
main power supply is disconnected.
- Switch off the machine and disconnect the
power cable.
- Remove the main cover.
- Wash and sanitize your hands and forearms.
- Unscrew the bowl knobs (fig.14).
- Simultaneously press the two securing tabs
and lift the tap to extract it from its seat (see
fig.15).
- Disassemble the tap by keeping the body
pressed down and slipping the lever from its
seat (fig.15).
Caution
To prevent bacteria growth, remove all
o-rings when cleaning.
Failure to do so could create a health
hazard.
- Pull the bowl outward, as shown, to
completely remove it from its seat (fig.16).
Fig. 14
Fig. 15
Fig. 16
