Positive battery cable connection
DIP switches
Negative battery cable connection
Mounting plate
Accessories terminal block for switches 5-8
Input terminal block
Jumper for input polarity selection
Controller inputs (Ethernet cable)
2AMP fuse for circuit board protection
Cover. Do NOT remove or warranty will be voided
Accessories terminal block for switches 1-4
Reverse polarity warning lights (lights red if reverse polarity is detected
Thumb screw for fastening lid
Place holders for switch ID labels (legends)
Auxiliary port identifcations
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
COMPONENTS
1
2 3
4
5
6789
10
11
12
13 14
15
