HACK ATTACK™ BASEBALL PITCHING MACHINE
SPORTS ATTACK, LLC. • 800-717-4251 • sportsattack.com
5
Set-up & Preparation
SET-UP & PREPARATION
1. Install the rear leg (NOTE: the leg has a push button, which locks the leg into the
socket). Roll Hack Attack onto the mound approximately four feet in front of the rubber.
2. Be sure the horizontal swivel lock is tightened securely.
3. Tilt Hack Attack forward until it rests on the throwing wheel guard.
4. Insert the two front legs into the front sockets in the undercarriage (NOTE: the front
legs also have locking push buttons).
5. See Figure 2 on page 4.
Walk around to the front of Hack Attack, and, with your back to home plate, reach
down and grasp the wheel guards. Then, lift Hack Attack up and over the front legs
and set it gently onto the rear leg.
6. Position Hack Attack:
a. To approximate the release point of a live pitcher, position Hack Attack so that the
rear leg is just in front of the rubber.
b. Then, sight down ball chute. Move the rear leg right or left to adjust machine so
that it is pointing directly at home plate.
c. Check the horizontal swivel lock to make sure it remains tight.
7. Unlock the travel lock. Turn the handle of the elevation control counter-clockwise
until the bar of the travel lock snaps back out of the way.
8. Adjust the throwing head:
a. Turn the handle of the elevation control clockwise. Raise the throwing head until
it will throw somewhere near the required height.
b. This initial adjustment will come through experience. To start, turn the elevation
adjustment 10 turns clockwise.
9. Examine Hack Attack for condition and completeness:
a. Be sure the horizontal swivel lock is secured.
b. Throwing wheels must be tight on the motor shafts. Check that the keyway retaining
bolts are tight.
c. Wheel guard and ball chute must be securely fastened to the throwing head.
10. Be certain on/off switch is turned “OFF”, then plug Hack Attack into an extension
cord or other power source. (See generator information at right if applicable.)
WARNING
HAZARD FROM
HIGH-SPEED PROJECTILES
Being struck by a pitched ball
can cause serious injury or death.
Make sure that no one steps in
front of Hack Attack while it is
connected to electric power.
Clear all hitters away from home
plate, the batter’s box and the
backstop area before connecting
Hack Attack to electric power.
GENERATOR INFORMATION
1. Hack Attack requires a
generator capable of providing
clean electricity 2000 watts at
120 volts 60hz.
2. Be sure the on/off switch is
“OFF” before plugging Hack
Attack into the generator.
3. Start the generator and allow
it to reach full speed before
turning the on/off switch “ON”.
IMPORTANT: Generator speed
fluctuations can damage the
electronic speed control. Maintain
adequate fuel in the generator at
all times.
4. Turn the on/off switch “OFF”
before shutting off the
generator and before
unplugging Hack Attack.
