SPORTSTECH F10 - Assembly Instructions

28
3. ASSEMBLY INSTRUCTIONS
59
61
54
15 62 16
Console Knob
x 2
Hex Screw M8X15
x 2
Spring Washer
x 2
Hex Screw M8X50
x 2
Safety Key
x 1
Allen Key
x 1
Step 1
A. Place the treadmill in the upright position on a level flat surface.
B. Lift the Left Stand Tube (3) and Right Stand tube (4) up, insert the Hex Screw M8X50 (15) and Hex Screw
M8X15 (16) into the holes on the Base Frame (1), tighten them by Allen Key.
5 easy steps to assemble your treadmill then you‘re ready to workout.
TOOL KIT
Handlebar Cover
x 2
3
15
15
1
62
62
16
16
4
