Spring Well CSS1 - Installing the Brine Tank; Brine Tank Drain and Regen Line

Installing the Brine Tank
83) Remove the white cap from
the brine well inside the brine
tank.
79) Press the remaining drain
line over the barbed valve
leading out from the brine tank.
80) Thread the drain line into
the drainpipe and trim off the
excess drain line.
81) Use the previous steps to
secure the drain line to the
drainpipe.
82) Remove the lid from the
brine tank.
This step will require the materials listed below
78) Position the brine tank next to
the softener tank with the drain
valve pointing towards the
softener.
Questions? Call (800)-589-5592 17
84) Release the regen line from
the softener head by removing
the zip ties. Use care not to
damage the line.
Whole House Filter and Water Softener
Softener Tank
(Already Installed)
Tank
2
50’ Drain Line
Zip Ties
Brine
Tank
