Springfield 91066 - Advanced Features and Product Installation; Max.;Min. Feature & Daily Reset Option; Product Installation

WIRE ATTACHMENT
SCREW
SENSOR
PROBE
OUTDOOR
INDOOR
WALL
below range. The outdoor temperature will also read LL.L if the detachable probe is not plugged
into the jack.
Max./Min. Feature & Daily Reset Option:
Press the MAX/MIN button once to display the maximum indoor and outdoor temperature
readings. When the maximum temperature readings are being displayed, MAX will appear in
the lower-left portion of the LCD window.
Press the MAX/MIN button a second time to display the minimum indoor and outdoor
temperature readings. When the minimum temperature readings are being displayed, MIN will
appear in the lower-left portion of the LCD window.
To return to the current temperature readings, press the MAX/MIN button again.
The max/min temperature memory can be manually reset when desired by pressing the RESET
(SET) button while in the MAX/MIN function mode. The max/min memory is now cleared and
the unit will start measuring the maximum and minimum temperatures from this point.
The daily reset function can be engaged to automatically reset the maximum and minimum
temperature readings daily at 12:00 AM. To enable this function, slide the DAILY switch at the
back of the unit to the ON position. To disable this function, slide the switch to the OFF
position.
Please note: If the DAILY function is in the ON position, DAILY MAX or DAILY MIN will
appear in the lower-left portion of the LCD window.
PRODUCT INSTALLATION
Choose a suitable place for the product and outdoor sensor. Place the unit near a window, but
away from direct sunlight or other sources of heat or air conditioning to ensure accurate air
temperature reading. The weather center can either stand upright or hang on a wall utilizing the
nail/screw slot in the back of the unit.
To Wall Mount Unit:
1. Drive a screw into the wall at the desired location until the head extends 1/8” from the wall.
2. Position the slot at back of unit over the top of the screw head and then slide down until the
thermometer is locked into place.
For accurate outdoor air temperature readings in summertime
or wintertime, the sensor should be placed approximately one
inch away from the house wall or windowpane using the
metal wire hanger enclosed.
To Mount External Sensor to Outside Wall:
1. Drive a screw into the wall at the desired location.
2. Route the external probe cable through the window.
3. Position the external probe into wire attachment.
