SpringWell CF+ - System Contents; Setup and Installation; Recommended Supplies; System Configuration

Setup And Installation
System Contents
Carbon Filter
Tank (CF+)
Pre-Filter
Gasket and Lube
Spanner
Wrench
Sediment
Filter
Mounting
Bracket
Recommended Supplies
Primer and Cement
1.5-inch Tee
Connector (Slip) (x2)
1 Roll Plumbers
Tape
1.5-inch PVC Pipe (10’ used in this
manual)
1.5-Inch PVC Shut Off
Valves (x3)
System Configuration
Water Source
From Outside Home
Filtered and Softened
Water Into Home
(1) Water from your
source will begin by
entering the Pre-Filter
(2) The Carbon Filter
Filter (CF+) will be the
second tank and will
remove chemicals such
as chlorine
1
2
Hose Bib
Assembly (2)
1.5-inch Elbow
Connector (Slip) (x8*)
1.5-inch Adapter (Slip
x Thread) (x4)
CF+ System
Questions? Call (800)-589-5592 2
* The quantities are suggestions. Your system configuration may vary depending on installation area.
