Installing the Tank
59) Connect the PVC to the
inlet on the CF+ tank.
55) Connect a 1.5-inch adapter
to the inlet and outlet on the
tank. Fully tighten.
56) Make note of the water
flow direction on the tank.
57) The Carbon Filter Tank will
now be installed. Stage it inline
with the pre-filter.
58) Cut a piece of PVC to bridge
between the outlet of the pre-
filter to the inlet on the CF+ tank
and install into the pre-filter.
Carbon Filter
Tank
This step will require the materials listed below
Plumbers Tape
1.5-inch Adapter (Slip x
Thread)(x2)
1.5-inch Elbow
Connector (Slip) (x2*)
1.5-inch PVC Pipe (Cut to fit)
54) Note: Plumbers tape will need
to be applied to all PVC threads
during the installation.
Questions? Call (800)-589-5592 12
* The quantities are suggestions. Your system configuration may vary depending on installation area.
60) Start to build the connection
to the CF+ tank from the other
side of the bypass. Insert a piece
of PVC into the shut off valve.
CF+ System
To Next Page
