SpringWell CF+ - Page 11

Installing the Pre-Filter (cont.)
47) Fully tighten the bolts.
51) Connect an elbow pointing
towards the pre-filter inlet.
46) The other 4 bolts will be used
to secure the pre-filter housing to
the bracket.
48) Now connect the pre-filter
to the incoming side of the
bypass you built earlier. Start by
adding a length of PVC to lead
towards the inlet of the pre-
filter.
49) Add an elbow facing
towards the pre-filter inlet.
50) Add another length of PVC to
reach the inlet connection of the
pre-filter.
52) Add a final piece of PVC to
connect the incoming water
flow to the inlet on the pre-
filter.
53) The pre-filter is now installed.
Your system should look similar
to this.
45) Take note of the in versus out
flow markings on the top of the
pre-filter housing. Mount the pre-
filter housing to allow for optimal
routing for your plumbing.
Questions? Call (800)-589-5592 11
