PARTS IDENTIFICATION
2
Your dishwasher comes equipped with a 'quick connect' assembly (includes inlet and drain hose). The
faucet adapter must be installed on the faucet before you can connect the dishwasher. This adapter is
installed on the Quick Connect. The faucet adapter is compatible with faucets inclusive of either male
(outside) or female (inside) threaded faucet connections.
In order to avoid water pressure build up, please turn off the faucet after each use.
WARNING!
ACCESSORIES
Basket
3
5
7
8 9
Filter assembly
Rinse Aid
Dispenser
Inlet pipe
connector
Detergent Dispenser
3
6
Cutlery Basket
5
8
Spray Arms
7
Drain pipe
connector
9
Cup Shelf
1
2 4
1
2 4
6
