MACHINE OPERATION
The Model 1205 Supper Style Straight Conveyor, has been designed to carry
the product from the unloading and elimination area to the Piler.
1. Check all bolts and hinge points to make sure they are tight and in good condition.
2. Properly ground all Electrically Operated Equipment.
3. Make sure the conveyor is level, and connected securely to the other conveyors if
any.
4. DO NOT plug the conveyor in with the power ON.
5. Be sure the switches on the main electrical panel or panels on the conveyor are
turned to “OFF”. Also, ensure that the Conveyor System switch on the machine
the conveyor is connected with is turned to “OFF”.
6. Check the voltage label on the main electrical panel to make sure that it is the
same voltage and phase as the rest of the system.
7. Make sure all electrical panel doors are closed and there is no one working on the
equipment and every one is clear of the system.
8. Make sure that all of the connectors and plugs on the machine are attached, and
are clear of water and other materials.
9. Test the belt direction on a three-phase conveyor by turning the switch on the
electrical panel to “HAND” briefly. Turning the switch to “AUTO” allows the
conveyor to run with the rest of the system.
10. Turn the Conveyor System switch on the machine the conveyor is connected with
to “ON”.
11. If you have a newer model, there is an emergency red “STOP” button in the
middle of each main electrical panel. This button will stop the entire system when
pushed. To restart, in “AUTO”, go to the machine that runs the system and push
the start button.
Warning!
The Emergency Stop Button will not function with the switch in the “HAND” position.
04/25/02
11
