SSSC-3
BELT DRIVE ASSEMBLY
ITEM # PART # DESCRIPTION QTY
24” WIDE CONVEYOR
1 881045 SPRCKT,H60BS24 X 1-1/4” 1
2 821053 SHFT,SK,1-1/4” X 31-1/2” (10) 1
3 502203 KEY,SQUARE,1/4” X 1-1/2” C1018 2
30” WIDE CONVEYOR
1 881120 SPRCKT,H60BS24 X 1-7/16”BORE 1
2 821210 SHFT,SK,1-7/16”X 37-1/2” (10) 1
3 501267 KEY,SQUARE,3/8” X 1-1/2” C1018 2
36” WIDE CONVEYOR
1 881120 SPRCKT,H60BS24 X 1-7/16”BORE 1
2 821108 SHFT,SK,1-7/16”X 43-1/2” (10) 1
3 501267 KEY,SQUARE,3/8” X 1-1/2” C1018 2
4 351005 CHN,RLR,60 PITCH (56” LONG) 1
5 351010 LINK,CHN,RLR,MASTER,60 PITCH 1
6 841110 SHLD,OVAL,HINGED,W/BACK,3” X 9” X 28”
(FOR BOTTOM MOTOR MOUNT ONLY -STD)
1
OR
841112 SHLD,OVAL,HINGED,W/BACK,3” X 9” X 30”
(FOR TOP MOTOR MOUNT ONLY) NOT SHOWN
1
7 881039 SPRCKT,H60BS18x1" BORE 1
8 502203 KEY,SQUARE,1/4” X 1-1/2” C1018 1
24” WIDE CONVEYOR
9 231097 BRNG,TU,1-1/4”BORE ECC LOCK ASSY 9” BOLT 2
A 231100 BRNG,TU,1-1/4” ASSEMBLY W/O BEARING 1
B 231092 BRNG,INSERT,1-1/4” ECCENTRIC LOCK/SPHR 1
10 781056 BUSHING,P1x1-1/4" BORE SPLIT TAPER 2
11 781201 RLR,LGD,5"ODx23-1/2" TL 1
CONTINUE NEXT PAGE
