SSSC-3
BELT DRIVE ASSEMBLY
ITEM # PART # DESCRIPTION QTY
30” WIDE CONVEYOR
9 231098 BRNG,TU,1-7/16”BORE ECC LOCK ASSY 9”BOLT 2
A 231101 BRNG,TU,1-7/16” ASSEMBLY W/O BEARING 1
B 231091 BRNG,INSERT,1-7/16” ECCENTRIC LOCK/SPHR 1
10 781184 BUSHING,P1x1-7/16" BORE SPLIT TAPER 2
11 781203 RLR,LGD,5"ODx29-1/2" TL 1
36” WIDE CONVEYOR
9 231098 BRNG,TU,1-7/16”BORE ECC LOCK ASSY 9”BOLT 2
A 231101 BRNG,TU,1-7/16” ASSEMBLY W/O BEARING 1
B 231091 BRNG,INSERT,1-7/16” ECCENTRIC LOCK/SPHR 1
10 781184 BUSHING,P1x1-7/16" BORE SPLIT TAPER 2
11 781204 RLR,LGD,5"ODx35-1/2" TL 1
NOTE: Item 9. These bearings are of a sealed type and lubricated by manufacturer.
The bearings will only need greased at the start of season. One pump of grease
is sufficient. Over greasing sealed bearings will result in the seal being broken
and rapid failure of the bearing. If seal is broken greased the bearing daily until
replaced.
