SSSC-6
12” CRAZY WHEEL ASSEMBLY
ITEM # PART # DESCRIPTION QTY
131480 ASSY,CRAZY,WHEEL,12" W/LOCK PLATE 1
1 501198 BOLT,HEX,HD,1”-8UNC x 8” GR 5 BLACK 1
2 171124 BRACKET,CRZY,WHL 8” x 12” BARE 1
3 951022 HUB,COMPLETE,4 HOLE #H44O-BT
(REFER TO SECTION SSSC-5, PAGE 20)
1
4 501713 NUT,LOCK,HEX,1”-8UNC NYLON INSERT 1
5 171857 SPACER,PIPE,1-1/4” LG,8”&12” CRAZY WHEEL 1
6 171856 SPACER,PIPE,1” LG,8”&12” CRAZY WHEEL 1
7 951101 TIRE,&RIM,480 x 12” TUBELESS MOUNTED
(REFER TO SECTION SSSC-5, PAGE 20)
1
4/25/2002
21
item 2 should be 171610 BRACKET,CRZY,WHL,8"&12" W/LOCK PLT BARE
