SSSC-8
AXLE ASSEMBLY
ITEM # PART # DESCRIPTION QTY
1 131051 JACK,ASSY,18”,TELESCOPING ACME THRD
(REFER TO SECTION SSSC-7, PAGE 22)
4
2 501950 COLLAR,SHAFT,SET,SCREW,1-1/4” 4
3 231024 BRNG,THRUST,1-1/4”BORE TIMKEN T-126 4
4 131732 AXLE,CONV 24"CRAZY WHL W/LOCK1200/1205 2
OR
131733 AXLE,CONV 30"CRAZY WHL W/LOCK1200/1205
OR
131734 AXLE,CONV 36"CRAZY WHL W/LOCK1200/1205
5 131047 ASSEMBLY,CRAZY,WHEEL,12”
(REFER TO SECTION SSSC-6, PAGE 21)
4
Revised: Add part numbers for axle weldments Item 4, 08/30/01.
4/25/2002
