SSSC-9
ADJUSTABLE END ASSEMBLY
ITEM # PART # DESCRIPTION QTY
1 TONGUE,TOW,CONVEYOR,MDL 1205 SS STR
(REEFER TO SECTION SSSC-11, PAGE 28)
1
24” WIDE CONVEYOR
2 181510 RP,18” 2” X 16”PIPE 3/4”SHAFT DT3/8” 1
A 821004 SHFT,DT,3/4” X 18” DT3/8” 1
B 181124 PIPE,PR,2”X 16”LONG 1
C 231106 BRNG,INSERT,3/4”BORE 1.75”OD TW-18 SHATZ 2
D 501901 COLLAR,SHAFT,SET,SCREW,3/4” 2
30” WIDE CONVEYOR
2 181497 RP,24” 2” X 22”PIPE 3/4”SHAFT DT3/8” 1
A 821008 SHFT,DT,3/4” X 24” DT3/8” 1
B 181125 PIPE,PR,2” X 22”LONG 1
C 231106 BRNG,INSERT,3/4”BORE 1.75”OD TW-18 SHATZ 2
D 501901 COLLAR,SHAFT,SET,SCREW,3/4” 2
36” WIDE CONVEYOR
2 181498 RP,30” 2” X 27”PIPE 3/4”SHAFT DT3/8” 1
A 821012 SHFT,DT,3/4” X 30” DT3/8” 1
B 181302 PIPE,PR,2” X 27”LONG 1
C 231106 BRNG,INSERT,3/4”BORE 1.75”OD TW-18 SHATZ 2
D 501901 COLLAR,SHAFT,SET,SCREW,3/4” 2
3 191686 BOLT,WELD,ALL THREAD 5/8" x 14" 2
4 BEARING,
(REFER TO SECTION SSSC-3 , PAGE 17, ITEM 6)
2
24” WIDE CONVEYOR
5 781179 PSC,TL,23-1/2” 6-3/16”OD 1
6 821052 SHFT,SK,1-1/4” X 29-1/2” (10) 1
7 781056 BUSHING,P1 X 1-1/4”BORE SPLIT TAPER 2
30” WIDE CONVEYOR
5 781180 PSC,TL,29-1/2” 6-3/16”OD 1
6 821105 SHFT,SK,1-7/16” X 35-1/2” (10) 1
7 781184 BUSHING,P1 X 1-7/16”BORE SPLIT TAPER 2
CONTINUE NEXT PAGE
