SSSC-9
ADJUSTABLE END ASSEMBLY
ITEM # PART # DESCRIPTION QTY
36” WIDE CONVEYOR
5 781181 PSC,TL,35-1/2” 6-3/16”OD 1
6 821107 SHFT,SK,1-7/16” X 41-1/2” (10) 1
7 781184 BUSHING,P1 X 1-7/16”BORE SPLIT TAPER 2
8 171200 END,ADJUSTABLE,CONV,SS,LH FACING INTAKE 1
9 171199 END,ADJUSTABLE,CONV,SS,RH FACING INTAKE 1
NOTE:
Please asks about the Retrofit Hitch Kit for older conveyor. This Kit will allow
you to use the Tow Tongue on all Your Spudnik Super Style Straight Conveyors
in your system.
This Kit includes a WHEEL LOCK that has to be welded on the discharge
end of the conveyor.
Tow Tongues are not included in this Retrofit Hitch Kit.
(Refer to Section SSSC-12, Page 27)
.
RETROFIT HITCH KIT;
#171372 - HITCH,KIT,24”,RETROFIT,MDL 1205
#171373 - HITCH,KIT,30”,RETROFIT,MDL 1205
#171374 - HITCH,KIT,36”,RETROFIT,MDL 1205
4/25/2002
25
