Spudnik 1205 - Page 41

SSSC-10
PIPE ROLLER PLACEMENT
ITEM # PART # DESCRIPTION QTY
1 501932 WASHER,LOCK,SPLIT,3/8” 2
2 501049 BOLT,HEX,HD,3/8”-16UNC X 1” GR5 2
3 181008 RP,24-1/2” 2” X 16”PIPE ¾”SHAFT DT3/8”
(24”WIDE CONVEYOR) SEE NOTE FOR QTY.
OR
181012 RP,30-1/2” 2” X 22”PIPE ¾”SHAFT DT3/8”
(30”WIDE CONVEYOR) SEE NOTE FOR QTY.
OR
181017 RP,36-1/2” 2” X 27”PIPE ¾”SHAFT DT3/8”
(36”WIDE CONVEYOR) SEE NOTE FOR QTY.
NOTE: ITEM #3, CARRIER PIPE ROLLER;
20’ CONVEYOR ………………. QTY = 8
24’ CONVEYOR ………………. QTY = 10
30’ CONVEYOR ………………. QTY = 13
40’ CONVEYOR ………………. QTY = 18
These QTY are for standard lengths. For custom lengths add or subtract ONE (1) roller
for each TWO (2) feet of conveyor.
4 181342 RP,24-1/2” 2” X 22”PIPE ¾”SHAFT DT3/8”
(24”WIDE CONVEYOR) SEE NOTE FOR QTY.
OR
181244 RP,30-1/2” 2” X 27”PIPE ¾”SHAFT DT3/8”
(30”WIDE CONVEYOR) SEE NOTE FOR QTY.
OR
181343 RP,36-1/2” 2” X 33”PIPE ¾”SHAFT DT3/8”
(36”WIDE CONVEYOR) SEE NOTE FOR QTY.
NOTE: ITEM #4, CARRY BACK PIPE ROLLER;
20’ CONVEYOR ………………. QTY = 1
24’ CONVEYOR ………………. QTY = 1
30’ CONVEYOR ………………. QTY = 2
40’ CONVEYOR ………………. QTY = 3
These QTY are for standard lengths. For custom lengths add or subtract one (1) roller
for each TEN (10) to TWELVE (12) feet of conveyor.
