SPX FLOW Deltech ZP Series User Manual

41
MODEL
500 600
MAINTENANCE KITS
Year 2 Maintenance Kit Elements*, Mufer, Drain, Desiccant Evaluation Kit ZPMK2-04 ZPMK2-06
Year 3 Maintenance Kit
All the contents of the 2 Year Kit, Pressure
Switches, Valve Repair Kits, Blower Hose
ZPMK3-04 ZPMK3-06
Year 4 Maintenance Kit Elements*, Mufer, Drain, Desiccant Evaluation Kit ZPMK4-04 ZPMK4-06
Year 5 Maintenance Kit
All the contents of the 4 Year Kit, Pressure
Switches, Valve Repair Kits, Blower Hose
ZPMK5-04 ZPMK5-06
Desiccant Kit ZPDES-04 ZPDES-06
*NOTE: For dryer’s shipped with optional pre-piped F0 or F3 Filter packages, add “-A” for year 2 - 5 kits. (Replacement Prelter and Afterlter elements are not included in Standard Kits.)
REPLACEMENT PARTS
SAFETY
STOCK
DRYER
QTY.
ID# DESCRIPTION
1 Inlet Valve Assembly (V1 & V2)
3151877 3151877 1 2
* Solenoid Valve (Sol “A”, “B”) 3203652 3203652 1 2
2 Purge Exhaust Valve Assembly (V3 & V4) 3152701 3152701 1 2
* Solenoid Valve (Sol “C”, “D”) 3203652 3203652 1 2
3 Purge Check Valve (V5 & V6) 3160401 3160401 1 2
4 Outlet Check Valve (V7 & V8) 3160401 3160401 1 2
5 Depress Valve (V9, V10) 7438612 7438612 1 2
* Depress Solenoid Valve (Sol “F”, “G”) 3203652 3203652 1 2
6 Purge Heater 3152742 3152741 1
7 Heater Temperature Thermocouple (1TC) 3153971 3153971 1
8 Heater Overtemperature RTD (RTD3) 3153224 3153224 1
9 Chamber RTD (RTD1, RTD2) 3153224 3153224 1 2
10 Pressure Relief Valve 7400684 7400684 1
11 Chamber Pressure Gauge 7450553 7450553 1 2
12 Chamber Pressure Switch (1PS, 2PS) 3149016 3149016 1 2
* Chamber Depressurization Pressure Switch (3PS, 4PS) 3152525 3152525 1 2
14 Pilot Air Filter Element 3158592 3158592 1 1
15 Pilot Air Pressure Regulator 3154237 3154237 1
17 Depress Mufer 3133635 3133635 2
* Depress Mufer Replacement Core 3075949 3075949 2 2
23 Purge Pressure Gauge 7450569 7450569 1
24 Blower (460V) 3157984 3158197 1
* Blower Hose 3251999 3242540 1
25 Silencer Assembly 3152461 3152461 1
* Blower Inlet Silencer Element 1270769 1270769 1
26 Repress/Sweep Valve (V11) 7438612 7438612 1 1
* Repress/Sweep Solenoid Valve (Sol “E”) 3203652 3203652 1 1
27 Repress/Sweep Check Valve (V12 & V13) 3151005 3151005 1 2
29 Chamber Blowdown Valve 4009894 4009894 2
42 Energy Management Pilot Operated Valve 1274209 1274209 1
43 Energy Management Sensor (RTD4/HS1) 3144864 3144864 1
* Energy Management Vent Needle Valve 3158747 3158747 1
44 Dew-point Sensor - Ceramic 3154859 3154859 1
* Dryer Controller 7417845 7417845 1
* Heater Contactor 3157896 3157896 1
* Blower Motor Contactor 3147640 3147640 1
* Relay, Overload, 3Pole, 600V Max, 3.2-16Amp 3158551 3158551 1
* Relay, SPDT 12VDC Coil, 120VAC, 10A (1CR, 2CR, 3CR, 4CR, 5CR) 3154359 3154359 1 5
* Fuse 1.25A 600V (3FU) 1240671 1240671 1 1
* Fuse .5A 600V (1FU, 2FU) 1241118 1241118 1 2
* Temperature Controller 7416897 7416897 1
* Timer, SPDT, 0.1S-120HR 3203083 3203083 1
Desiccant Evaluation Kit 3150628 3150628
Pre-Filter Assembly DF625-B-20-DG DF625-B-20-DG
Auto-Drain 3152270 3152270
Afterlter Assembly DTA600 DTA600
NOTES:
1. Parts and Maintenance Kits are for standard builds only. Please contact the factory with your dryer serial number for assistance on identifying spare parts and maintenance kits for your specic unit.
2. All quantities for one dryer.
3. ID# correspond to P&ID legend (* Not pictured in diagrams.)
Phone: +1 724 745 8647
Email: ft.dehydration.order.entry@spxow.com
Web: www.spxow.com/deltech
