SPX FLOW Deltech ZP Series User Manual

47
MODEL
3200 3600 4300
MAINTENANCE KITS
Year 2 Maintenance Kit Elements*, Mufer, Drain, Desiccant Evaluation Kit ZPMK2-24 ZPMK2-26 ZPMK2-28
Year 3 Maintenance Kit
All the contents of the 2 Year Kit, Pressure
Switches, Valve Repair Kits, Blower Hose
ZPMK3-24 ZPMK3-26 ZPMK3-28
Year 4 Maintenance Kit Elements*, Mufer, Drain, Desiccant Evaluation Kit ZPMK4-24 ZPMK4-26 ZPMK4-28
Year 5 Maintenance Kit
All the contents of the 4 Year Kit, Pressure
Switches, Valve Repair Kits, Blower Hose
ZPMK5-24 ZPMK5-26 ZPMK5-28
Desiccant Kit ZPDES-24 ZPDES-26 ZPDES-28
*NOTE: For dryer’s shipped with optional pre-piped F0 or F3 Filter packages, add “-A” for year 2 - 5 kits. (Replacement Prelter and Afterlter elements are not included in Standard Kits.)
REPLACEMENT PARTS
SAFETY
STOCK
DRYER
QTY.
ID# DESCRIPTION
1 Inlet Valve Assembly (V1 & V2)
7448896 7448901 7448901 1 2
* Solenoid Valve (Sol “A”, “B”) 3203652 3203652 3203652 1 2
1A Inlet Pilot Operated Valve 3155189 3155189 3155189 1 2
2 Purge Exhaust Valve Assembly (V3 & V4) 7448895 7448895 7448895 1 2
* Solenoid Valve (Sol “C”, “D”) 4009880 4009880 4009880 1 2
* Solenoid Valve Coil (Sol “C”, “D”) 4009810 4009810 4009810 1 2
3 Purge Check Valve (V5 & V6) 3160064 3160064 3160064 1 2
4 Outlet Check Valve (V7 & V8) 3160061 3160061 3160061 1 2
5 Depress Valve (V9, V10) 7438613 7438613 7438614 1 2
* Depress Solenoid Valve (Sol "F", "G") 3203652 3203652 3203652 1 2
6 Purge Heater 1181451 1185499 1276268 1
7 Heater Temperature Thermocouple (1TC) 3153971 3153971 3153971 1
8 Heater Overtemperature RTD (RTD3) 3153224 3153224 3153224 1
9 Chamber RTD (RTD1, RTD2) 3153224 3153224 3153224 1 2
10 Pressure Relief Valve 3100938 3100938 3119442 1
11 Chamber Pressure Gauge 7450553 7450553 7450553 2
12 Chamber Pressure Switch (1PS, 2PS) 3149016 3149016 3149016 1 2
* Chamber Depressurization Pressure Switch (3PS, 4PS) 3152525 3152525 3152525 1 2
14 Pilot Air Filter Element 3158592 3158592 3158592 1 1
15 Pilot Air Pressure Regulator 3154237 3154237 3154237 1
17 Depress Mufer 3130773 3130773 3130773 2
* Depress Mufer Replacement Core 3121200 3121200 3121200 1 2
23 Purge Pressure Gauge 7450569 7450569 7450569 1
24 Blower (460V) 3158474 3158475 3158475 1
* Purge Blower Throttling Valve 1170918 1170918 1170918 1
* Expansion Joint 1206327 1206327 1206327 1
25 Purge Suction Filter Silencer Assembly 3032795 3032795 3032795 1
* Blower Inlet Silencer Element 3504482 3504482 3504482 1 1
26 Repress/Sweep Valve (V11) 7438613 7438614 7438614 1 1
* Repress/Sweep Solenoid Valve (Sol ‘E’) 3203652 3203652 3203652 1 1
27 Repress/Sweep Check Valve (V12 & V13) 3152094 3152095 3152095 1 2
29 Chamber Blowdown Valve 4009900 4009900 4009900 2
30 Heater High Inlet Temperature Switch (1TS) 3159879 3159879 3159879 1
42 Energy Management Pilot Operated Valve 1274209 1274209 1274209 1
43 Energy Management Sensor (RTD4/HS1) 3144864 3144864 3144864 1
* Energy Management Vent Needle Valve 3158747 3158747 3158747 1
44 Dew-point Sensor - Ceramic 3154859 3154859 3154859 1
* Dryer Controller 7417845 7417845 7417845 1
* Heater Contactor 3158326 3158326 3158326 1
* Blower Motor Contactor 3149521 3149521 3149521 1
* Relay, Overload, 3Pole, 600V Max, 3.2-16Amp 3158481 3158481 3158481 1
* Relay, SPDT 12VDC Coil, 120VAC, 10A (1CR, 2CR, 3CR, 4CR, 5CR) 3154359 3154359 3154359 1 5
* Fuse 1.25A 600V (3FU) 1240671 1240671 1240671 1 1
* Fuse .5A 600V (1FU, 2FU) 1241118 1241118 1241118 1 2
* Timer, SPDT, 0.1S-120HR 3203083 3203083 3203083 1
* Temperature Controller 7416897 7416897 7416897 1
Desiccant Evaluation Kit 3150628 3150628 3150628
Pre-Filter Assembly DF5000-B-20-G DF5000-B-20-G DF5000-B-20-G
Auto-Drain 3044466 3044466 3044466
Afterlter Assembly DTA4800 DTA4800 DTA4800
NOTES:
1. Parts and Maintenance Kits are for standard builds only. Please contact the factory with your dryer serial number for assistance on identifying spare parts and maintenance kits for your specic unit.
2. All quantities for one dryer.
3. ID# correspond to P&ID legend (* Not pictured in diagrams.)
Phone: +1 724 745 8647
Email: ft.dehydration.order.entry@spxow.com
Web: www.spxow.com/deltech
